* obt bearings, obt spherical roller thrust bearings, thrust spherical roller bearing.

Shandong Obetter Bearing Company (OBT ) spherical roller thrust bearings in assembling a large number of asymmetric rollers, and special Raceway has an excellent combination. Therefore can withstand the heavy load, and allows a relatively high speed. Spherical roller thrust bearings according to size and different series, there are two forms design; Model E suffix for the bearings, equipped with a ram Gangchuang-holder, and roller shaft circle formed an inseparable components. Bearing all other with copper or steel cage from the fixed axis circle hole in the sleeve to guidance, and with the roller shaft circle Cage composition of the device can not be separated.

Shandong Obetter Bearing Co.,Ltd spherical roller thrust bearing ranging from 60 mm till 800 mm in insidr diameter (ID).


internal structure :

E : Optimized internal design and pressed window-type steel cage
EF : Optimized internal design and machined steel cage
EM : Optimized internal design and machined brass cage
N1 : One locating slot in the housing washer
N2 : Two locating slots 180° apart in the housing washer
VE447 : Shaft washer with three equally spaced threaded holes in one side face to take hoisting tackle
VE447E :  Shaft washer with three equally spaced threaded holes in one side face to take hoisting tackle and three appropriate eye bolts
VE632 :  Housing washer with three equally spaced threaded holes in one side face to take hoisting tackle


we can produce non-standard bearing and machine parts as our customers request. we always follows the principles of "Good Faith, Equality, Cooperation and Win-Win" to cooperate with our customers.
For further information, please contact:
Company brand: OBT Bearing
Company Name: Shandong Obetter Bearing Co., Ltd
Tele: 86-635-8511972 /6
FAX: 86-635-8511972
WebSite:
www.obtbearing.com
E-mail:
obtbearing@163.com
MSN:
obtbearing@msn.com

Axial-Pendelrollenlager Butées à rotule sur rouleaux  Rodamientos axiales oscilantes de rodillos Cuscinetti assiali orientabili a rulli  Axiaal pendelrollagers Sfäriska axialrullager  Sfæriske aksialrullelejer Pallomaiset aksiaalirullalaakerit  Rolamentos axiais oscilantes de rolos  Sfæriske-Aksialrullelager  Łożyska baryłkowe wzdłużne Axiální soudečková ložiska Axiálne súdkové ložiská  Axiális beálló görgőscsapágyak Аксиални самонагаждащиролкови лагери Eksenel oynak makaralırulmanlar Роликоподшипники упорно-радиальные сферические
